Realistic programmeerbare AM-FM scanner

Beschrijving

Te koop aangeboden: nog goed werkende vintage Realistic scanner, typenummer 20.9115.

SPECIFICATIONS
GENERAL
Type:
VHF/UHF receiver/scanner
Frequency range:
68-88 / 108-136 / 138-174 / 410-512 MHz (Europe/Australia)
Tuning steps:
5 / 12.5 / 25 KHz
Frequency stability:
? ppm
Mode:
AM / FM
Channels / memory management:
20 regular
1 priority
RAM storage with a 9 V battery backup
Power supply:
Mains: 220-240 VAC (Fixed power cord)
or 13.8 VDC (2-pin connector)
Current drain / power consumption:
? mA @ 13.8 VDC
Antenna impedance / connector:
50-75 ohm / DIN41585 (Motorola)
Dimensions (W*H*D):
190*67*251 mm (7.5*2.62*9.88")
Weight:
? Kg (? lb)
Other features:
RECEIVER SECTION
Receiver system:
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
Sensitivity:
AM (No reference)
108-136 MHz: 1 uV
FM (No reference)
68-88 MHz: 0.5 uV
138-174 MHz: 0.5 uV
410-512 MHz: 1 uV
Selectivity:
18 KHz (-6 dB)
30 KHz (-50 dB)
Image rejection:
AF output power / speaker:
1.5 W at 10% distortion / ? ohm
External speaker connector:
MISCELLANEOUS
Manufactured:
Japan (By GRE), 1982-198x (Discontinued)
Additional info:
Related documents:
Modifications and fixes:
Reviews:
Options / Accessories:
-
